EMX PR-Loop Lite Preformed Vehicle Detection Loop

Description

EMX PR-Loop Lite Preformed Vehicle Detection Loop

The EMX Lite Preformed Loop is a ready-to-use solution for fast and easy loop installation. The Lite Loop provides built-in lightning protection and is available in a wide variety of standard sizes.

The Lite Loop is a rugged and flexible TPE tubing with an overall diameter of 0.26”. It is suitable for saw cut, tar, and concrete installations.

Features

• Rugged and flexible TPE tubing with an overall diameter of 0.26”
• Suitable for saw cut, tar, and concrete installation
• Built-in electronic lightning protection

Manufacturer’s Warranty

• 2 Years

Technical Specifications

• Operating Temperature: -20oC – +90oC
• Overall Diameter of Loop Wire: 0.26”
• Loop Dimensions: 2×6’ , 4×6’ , 4×8’ , 4×10’ , 6×10’ and 8×12’
• Lead-In-Wire: 50 feet long, twisted wire in PVC jacket
• Loop Wire Approvals: UL TC, PLTC, FPL or NPLF 300/600 Volt 40mil Nylon PVC direct burial

Product Literature

• EMX Lite Preformed Loop Spec Sheet
• EMX Lite Preformed Loop Manual
• EMX Lite Preformed Loop Size Chart
