Description
THCU Gate and Garage Door Universal Solid State Timer
- The compact and easily programmable THCU Gate and Garage Door Universal Solid State Timer is a universal AC/DC voltage solid state timer with a 2″ x 2″ configuration. The unit offers wide operating voltages: 19 to 265 VAC and 10 to 120 VDC. The ten-position binary dipswitch is easy to program. The unit has advanced digital circuitry that provides this timing module with unsurpassed accuracy and reliability.
Three fixed time ranges available:
- second to 102.3 seconds in 0.1-second increments
- second to 1023 seconds in 1-second increments
- 10 to 10230 seconds in 10-second increments.
- Extremely low off-state leakage current.
- Compact, easy to hook up, in-line installation.
- Vertical mounting option available with MB-1 Bracket.
- Totally encapsulated for protection from harsh environments.
- 100% Operational testing before shipping.
- Eliminates contactor “hum”.
- RoHS compliance available
